Bionic Tree Tower designed to blend with natural surroundings while supporting critical communication infrastructure

Büyük resim : Bionic Tree Tower designed to blend with natural surroundings while supporting critical communication infrastructure

Ürün ayrıntıları:

Menşe yeri:	Çin
Marka adı:	Jiayao
Sertifika:	ISO9001:2008 COC
Model numarası:	Biyonik Ağaç Kulesi

Ödeme & teslimat koşulları:

Min sipariş miktarı:	4 Ton
Fiyat:	US$1400-1600,1-100Tons;US$1000-1200,>=100 Tons
Ambalaj bilgileri:	Ahşap Kutularda Paketlenir veya Galvanizli Saclarla Paketlenir
Teslim süresi:	15 gün
Ödeme koşulları:	L/C, T/T
Yetenek temini:	Ayda 500 ton

İletişim Şimdi konuşalım.

Bionic Tree Tower designed to blend with natural surroundings while supporting critical communication infrastructure

Açıklama

Ürün adı:	35M Biyonik Ağaç Kulesi	Malzeme:	ASTM A36 A572 Sınıf50
Somun ve Cıvata:	Not 8.8/6.8/4.8	Sertifika:	ISO9001:2008 COC
Yükseklik:	10-40 Metre	Standart:	ANSI/TIA-222-G/H/F
Rüzgar Hızı:	0-300KM/H	Galvanizleme Standardı:	ASTM A123/ ISO 1461
Çevresel Etki:	Çevre dostu	Korozyon önleyici tedavi:	sıcak daldırma galvanizli
Ömür boyu:	20 yıldan fazla	Kaynak:	AWS D1.1
Renk:	şerit veya RAL Renk standart ve özelleştirilmiş	ağırlık:	Yaklaşık 2 ton
Bakım:	Periyodik temizlik sayesinde düşük bakım gereksinimi	Ek özellikler:	Gürültü azaltma, estetik kentsel tasarım
Tasarım:	Gerçekçi Ağaç Tasarımı	Tasarım ilhamı:	Doğal Ağaç Yapısı
Kurulum yerleri:	Kentsel alanlar, parklar ve sanayi bölgeleri	Şekil:	Ağaç benzeri
Konum:	Kentsel ortamlar	Çalışma gürültüsü:	Düşük gürültü salınımı
Estetik:	Doğal çevreye uyum sağlar
Vurgulamak:	Bionic Tree Tower for communication infrastructure , Natural blend Bionic Tree Tower , Bionic Tree Tower with warranty

Bionic Tree Tower designed to blend with natural surroundings while supporting critical communication infrastructure 0

JIAYAO CO., LTD

Bionic tree tower, also known as an artificial tree tower, is an innovative structure designed to replicate the look of natural trees while serving critical infrastructure purposes. Unlike traditional towers that often stand out visually, this tower blends seamlessly into landscapes, making it a preferred choice for areas where aesthetic harmony and functionality are both priorities.

1.Specifications

Design
1. Design Code	ANSI/TIA-222-G/H/F, EN 1991-1-4 & EN 1993-3-1
Structure Steel
2. Grade	Mild Steel	High Tensile Steel
	GB/T 700:Q235B, Q235C,Q235D	GB/T1591:Q355B, Q355C,Q355D
	ASTM A36	ASTM A572 Gr50
	EN10025: S235JR, S235J0,S235J2	EN10025: S355JR, S355J0,S355J2
3. Design Wind Speed	Up to 250 km/h
4. Allowable deflection	0.5 ~1.0 degree @ operational speed
5. Tension strength (Mpa)	360~510	470~630
6. Yield strength (t≤16mm) (Mpa)	355	235
7. Elongation (%)	20	24
8. Impact strength KV (J)	27(20°C)---Q235B(S235JR)	27(20°C)---Q345B(S355JR)
	27(0°C)---Q235C(S235J0)	27(0°C)---Q345C(S355J0)
	27(-20°C)---Q235D(S235J2)	27(-20°C)---Q345D(S355J2)
Bolts & Nuts
9. Grade	Grade 4.8, 6.8, 8.8
10. Standards for mechanical properties
10.1 Bolts	ISO 898-1
10.2 Nuts	ISO 898-2
10.3 Washers	ISO 6507-1
11. Standards for Dimensions
11.1 Bolts	DIN7990, DIN931, DIN933
11.2 Nuts	ISO4032, ISO4034
11.3 Washers	DIN7989, DIN127B, ISO7091
Welding
12. Method	CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
13. Standard	AWS D1.1
Marking
14. Method of marking of the members	Hydraulic Press Stamping
Galvanizing
15. Galvanization standard of steel sections	ISO 1461 or ASTM A123
16. Galvanization standard of bolts and nuts	ISO 1461 or ASTM A153

Core Structural & Design Features

Tree-Like Appearance: It features artificial trunks, branches, and even leaves made from durable materials like fiberglass or high-strength plastics, closely resembling real trees in shape, color, and texture.
Modular Construction: The tower is built with modular components, allowing customization in height (typically 5m to 30m) and “tree species” to match local flora, such as pine, palm, or oak trees.
Integrated Functionality: Equipped with hidden platforms, antenna mounts, and cable management systems to support telecommunications equipment (5G/4G antennas, microwave devices), environmental sensors, or even small wind/solar energy harvesters.

Key Materials & Manufacturing Standards

Primary Materials: High-quality fiberglass, UV-resistant plastics, and galvanized steel for the internal support structure, ensuring both durability and corrosion resistance.
Manufacturing Compliance: Follows industry standards like ASTM D256 for impact resistance of plastic components and ISO 1461 for galvanization, guaranteeing long-term performance in outdoor conditions.
Aesthetic Details: Leaves and branches are designed to withstand extreme weather (high winds, heavy snow) and maintain colorfastness for years, using advanced pigmentation techniques.

2.Product Detail
